Arashi 2.5″ TD05HR-BIG16G-10.5cm2 EVO 9MitsubishiLancer 4G63T Billet Wheel Ball Bearing Turbocharger

Arashis Bolt-on Upgraded Mitsubishi 4G63T Evolution VI-IX Replacement Turbocharger, directly replaces stock TD05HR turbo 49378-01570, 49378-01580,etc. Instant replacement with no hassle!

Brand New and Complete CHRAs balanced by VSR Core-Balancing Machine from Turbo Technics.

Application

Mitsubishi Lancer 4G63T Engine EVO 9 (EVO 4 – EVO 8)

Arashi Item No.

–

Replacement For.

Stock TD05HR Turbo P/N 49378-01570, 49378-01571, 49378-01580, 49378-01581, 49178-01595, MR552115, 060413028, 1515A054 etc.

Turbine Wheel

TD05HR (REVERSE)

Turbine Diameter

49 / 56mm (9 BladesPerformance High Inconel)

Turbine Housing

10.5cm^2 / 0.77 A/Rwith Ni 22% turbine housing which endures higher temperature

Compressor Housing

2.5″ inlet / 64 mm

Compressor Wheel

BIG16G (Billet REVERSE)

Compressor Diameter

48 / 68mm (6+6 Blades)

Compressor CFM

–

Cooling

Water & Oil Cooled(Water cooling must be used for ball bearing type)

Bearing

Dual-row ceramic ball bearing

Package Included

Oil and Water Line Kit with turbine gaskets / compressor outlet pipe/ extra springs

Flange

Standard EVO 9

Actuator

1.1 bar spring pre-installed on adjustable actuator.(18 ways for application)
